8 fibres armoured central loose tube cable, Euroclass Dca - s2, d2, a1, OS2 9/125 μm

P/N: CLTD08OS2-PANC-Dca

suitable for direct burial campus backbone applications, cable channels and cable bridges without the need of additional protection
100% protection against rodents
halogen-free LSFROH sheath
corrugated steel tape armor
central loose tube filled with water blocking gel
tensile elements made of glass yarns
contains rip cord
primary protection of 250 μm
resistant to mechanical damage, moisture, water, UV radiation, corrosive liquids, also resistant to welding spark
product group: structured cabling
packing: 2000m on drum

DATASHEET DECLARATION OF PERFORMANCE EKSPOLOATACINIŲ SAVYBIŲ DEKLARACIJA Декларация за Експлоатационни Показатели

Standard temperature range (installation)	-5 °C to +50 °C
Standard temperature range (operation)	-30 °C až +70 °C
Min. bending radius (installation)	154 mm
Min. bending radius (operation)	77 mm
Max. tensile load (installation)	1500 N (150 kg)
Max. tensile load (operation)	500 N (50 kg)
Outer cable diameter	7,7 mm
Weight	84 kg / km
Number of tubes x number of fibers	1 x 8
Reaction to fire	D_ca- s2, d2, a1
Fire safety	flame retardant, low smoke, zero halogen, non-corrosive

The determination of Reaction to Fire Class Performance of this cable has been performed by Product Certification Body notified by European Commision, which also carries out the assessment and verification of constant performance (AVCP) in the System 3.
