96 fibers outdoor multi loose tube cables, OS2 9/125 μm (ITU-T G.652.D)

Cable construction: Loose tube, Performance category: OS2 singlemode, Number of fibers: 96
P/N: MLTE096OS2-1.7
km
  • fully dielectric construction
  • tensile elements made of glass yarns
  • central fiberglass tensile element
  • primary protection of 250 μm
  • tubes filled with water blocking gel
  • suitable for outdoor environment
  • resistant to moisture, water and UV radiation
  • partial rodent protection (glass rodent protection - GRP)
  • ideal for horizontal campus installations using blowing and pulling technique

Technical specification

Standard temperature range (installation) -5 °C to +50 °C
Standard temperature range (operation) -40 °C to +70 °C
Min. bending radius (installation) 200 mm
Min. bending radius (operation) 150 mm
Max. tensile load (installation) 4000 N (200 kg)
Max. tensile load (operation) 1200 N (80 kg)
Outer cable diameter 10,0 mm
Weight 90 kg / km
Number of tubes x number of fibers 8 x 12
